- Growatt Inverter
- MAX 50KTL3 X LV
KERNEL PARAMERERS
- Input Voltage: 1100V
- Output Voltage: 230/400V
- Output Current: 96.6A
- Output Frequency: 50/60HZ
- Size: 860*600*300mm
- Certificate: CE,TUV
- Warranty: 5years
- Weight: 82kg
- AC Nominal Voltage: 220V/380V, 230V/400V (340-440V)
- MPPT voltage range: 200V-1000V
TECHNICAL PARAMETERS
| Datasheet | MAX 50KTL3 LV | MAX 60KTL3 LV | MAX 70KTL3 LV | MAX 80KTL3 LV |
|---|---|---|---|---|
| Max. recommended PV power ( tor module STC) | 75000W | 90000W | 105000W | 120000W |
| Start voltage | 250V | |||
| Nominal voltage | 585V | 585V | 600V | 600V |
| No. of MPP trackers | 6 | 6 | 7 | 7 |
| Max. input current per MPP tracker | 26A | |||
| Max. short-circuit current per MPP tracker | 32A | |||
| Output data (AC) | ||||
| AC nominal power | 50000W | 60000W | 70000W | 80000W |
| Max. AC apparent power | 55500VA | 66600VA | 77700VA | 88800VA |
| Nominal AC voltage（range*） | 220V/380V, 230V/400V (340-440V) | |||
| AC grid frequency（range*） | 50/60 Hz (45-55Hz/55-65 Hz) | |||
| Max. output current | 80.5A | 96.6A | 112.7A | 128.8A |
| AC grid connection type | 3W+N+PE | |||
| Efficiency | ||||
| MAX. efficiency | 98.80% | 98.80% | 99.00% | 99.00% |
| European efficiency | 98.40% | 98.40% | 98.50% | 98.50% |
