- GROWATT INVERTER
- MAX 100KTL3 X LV
KERNEL PARAMERERS
- Max.efficiency 98.4%
- Max. string input current 16A per string
- 10 MPPTs fuse free design
- AFCI protection
- With DC Switch
- Built-in Type II surge protection device both DC & AC side
- Intelligent IV diagnosis and active problem detection
- DC 2 in 1 connection
- IP66 rating
- 5 year warranty
TECHNICAL PARAMETERS
| Model | MAX 100KTL3-X LV | MAX 110KTL3-X LV | MAX 120KTL3-X LV | MAX 125KTL3-X LV |
|---|---|---|---|---|
| Input data (DC) | ||||
| Max.DC vatage | 1100V | |||
| Start voltoge | 195V | |||
| Nominal voltage | 600V | |||
| MPP vatage range | 180V-1000V | |||
| No.of MPP trackers | 10 | |||
| No. of PV strings per MPP trocker | 2 | |||
| Max.Input current per MPP tracker | 32A | |||
| Max.short-circult curent per MPP tracker | 40A | |||
| Output Data (AC) | ||||
| AC nominal power | 100000W | 110000W | 120000W | 125000W |
| Max.AC apparent power | 110000VA | 121000VA | 132000VA | 137500VA |
| Nominal AC voltage(range*) | 230V/400V[340-440VAC) | |||
| AC grid frequency(range*) | 50/60 Hz(45~55Hz/55-65 Hz) | |||
| Max.output cument | 158.8A | 174.6A | 190.5A | 198.5A |
| Adjustable power Factor | 0.8leading …0.8lagging | |||
| THDi | <3% | |||
| AC grid connection type | 3W/N/PE | |||
| Efficiency | ||||
| Max.efficiency | 98.80% | |||
| European efficiency | 98.40% | 98.50% | 98.50% | 98.50% |
| MPPT efficiency | 99.90% | |||
